SPECIFICATIONS

Brand Name: ANNKE
Origin: Mainland China
High Definition: 5.0 Megapixels
Supported Operating Systems: Windows 98
Supported Operating Systems: Windows XP
Supported Operating Systems: Windows Vista
Supported Operating Systems: Windows 7
Supported Operating Systems: Mac OS
Supported Operating Systems: Windows 8
Supported Operating Systems: No
Supported Operating Systems: Windows 10
Supported Operating Systems: Windows 2000
Supported Operating Systems: Windows 2008
Supported Operating Systems: Windows 2003
Lens (mm): 2.8mm
Style: Bullet Camera
Connectivity: RJ45
Installation: Normal
Installation: Wall Mounted
Minimum Illumination(Lux): F1.0
Scene: Indoor and outdoor
Color Night Vision: YES
Megapixels: 5MP
Video Compression Format: H.264
Video Compression Format: H.265
Color: WHITE
Color: black
Model Number: I81EM
IP Rating: IP66
Audio Output: Two Way Audio

• 1/1.8" Progressive Scan CMOS
• 3K full Color Network Speed Dome with 16:9 image scale
• Built-in microphone and speaker for real-time audio security
• Built-in memory card slot, support microSD card, up to 256 GB
• H.265+, H.265, H.264+, H.264
• DWDR, 3D DNR
• IP66
• 12 VDC and PoE (802.3af)
IP Camera
Camera
Image Sensor
1/1.8"Progressive Scan CMOS
Max resolution
3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display
Main Stream
50 Hz: 20fps(3072*1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 20fps(3072*1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Substream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate
32 Kbps to 8 Mbps
Lens
2.8 mm@F1.0
FOV
Horizontal FOV 105.7°, vertical FOV 57.3°, diagonal FOV 124.9°
Supplement Light
Smart white Light, up to 30 m
Min. Illumination
24 hour color: 0.001 Lux @(F1.0, AGC ON), 0 Lux with Light
Movement Range
Pan:0° to 340°, Tilt: -5° to 105°
Pan Speed
Configurable from 4° to 21°/s
Tilt Speed
Configurable from 4° to 19°/s
Audio Compression
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC-LC/PCM
Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps(MP2L2)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate
8 kHz/16 kHz
Environment Noise Filtering
Yes
Image Enhancement
3D DNR,BLC, HLC, WDDR
Protocols
IPv4/IPv6, HTTP, HTTPS, Qos, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP,FTP
API
Open Network Video Interface Version 18.12
Audio
Build in microphone & speaker, support 2-way audio
Basic Event
Motion detection, video tampering alarm, exception
General Function
Mirror, password protection, watermark
General
<
